Product Description
Specifications
| Manufacturer | Rogi |
| Model | X5750 |
| Condition | New |
| Item No | X5750 |
| Table size | 500 x 1600 mm |
| Max. table load capacity | 1800 kg |
| T-slots (number x width x pitch) | 5 x 18 x 80 mm |
| X axis travel (longitudinal) | 1200 mm |
| Y axis travel (cross) | 700 mm |
| Z axis travel (vertical) | 500 mm |
| Distance between spindle end and table top | 50 ~ 550 mm |
| Distance between spindle center and column ways | 45 ~ 745 mm |
| Swivel of universal milling head | 360° |
| Feed rate of X axis | 10-1000 mm/min variable |
| Feed rate of Y axis | 10-1000 mm/min variable |
| Feed rate of Z axis | 5-500 mm/min variable |
| Universal milling head spindle taper | ISO 50 |
| Universal milling head spindle speed | (27 steps) 30 ~ 2050 rpm |
| Torque of feed motor, X axis | 18 Nm, servo motor |
| Torque of feed motor, Y axis | 18 Nm, servo motor |
| Torque of feed motor, Z axis | 27 Nm, servo motor with brake |
| Power of universal milling head motor | 7.5 kW |
| Machine dimension | 2625 x 2460 x 2080 mm |
| Machine weight | 4200 kg |
