Heavy and vibration absorbing cast iron machine
Universal milling head swiveling 360°
Large, precise cross table
Large dimensioned handwheels for fine scale adjustment
Separate control panel
Central lubrication
Automatic mechanical rapid feed X and Y axis
Dovetail slideway
Motorised vertical movement Z-axis
Large chip tray
3-axis digital readout system
Coolant system
LED working lamp
Safety cover CE
Click to add this item to cart.
Product Description
Specifications
| Manufacturer | Rogi |
| Model | WUM100 |
| Condition | New |
| Item No | M1302 |
| Table size | 1120 x 260 mm |
| Table travel (X,Y) | 600 x 260 mm |
| Knee travel | 400 mm |
| Table power feed speed range (X) | 24 ~ 402 mm/min |
| Table power feed range (Y) | 24 ~ 402 mm/min |
| Knee rapid speed | 400 mm/min |
| T-slot | 3 x 14 – 63 mm |
| Distance spindle nose to table | 80 ~ 480 mm |
| Distance spindle axis to column | 0 ~ 600 mm |
| Max. end milling width | 125 mm |
| Max. vertical milling diameter | 25 mm |
| Spindle taper | ISO40 |
| Steps of spindle speeds | 11 |
| Range of spindle speeds | 40 ~ 1600 rpm |
| Spindle motor | 2.2 kW |
| Head swivel (L&R) | 360º |
| Overall dimension | 1655 x 1500 x 1730 mm |
| Net weight | 1480 kg |
